BAP-5 Stereo Preamplifier

Technical data:

• Number of inputs: five stereo
• Input type: four symmetrical (balanced), one asymmetrical, selected by rotary switch
• Input impedance: 47 kOhm
• Signal to noise ratio: 80dB
• Volume Control: 48-position, 4-section attenuator
• Volume control from the remote control – yes
• Voltage gain – 15 dB
• Frequency response -3dB (sine, 1W): 15Hz…300kHz
• Outputs: two – symmetrical and asymmetrical
• Output impedance: 600 Ohm
• Supply voltage: 230V +/- 10%, 50Hz
• Current consumption: minimum 0.2 at 230V
• Dimensions: 430mm x 370mm x 150mm
• Weight 9kg

  Price: PLN 24,900

BPA-250 Stereo Power Amplifier
Technical data:

• Number of inputs: two – balanced (XLR connector)
• Sensitivity at maximum gain: 1V
• Input impedance: 47 kOhm
• Signal to noise ratio – 80dB
• Continuous power (1 kHz sine): 250W per channel
• Speaker system impedance: 4, 8 or 16 Ohms
• Nonlinear distortion (8 Ohm, 1W, 20Hz…20kHz): less than 1%
• Frequency response -3dB (sine, 1W): 15Hz…30kHz
• Supply voltage: 230V +/- 10%, 50Hz
• Current consumption: minimum 0.5A maximum 3A at 230V
• Dimensions: 430mm x 370mm x 150mm
• Weight 12kg

  Price: PLN 19,900
